3 Review(s)

Book contain DC biasing of BJTs: Load lines, Operating Point, Fixed bias and Voltage-divider bias. DC bias with voltage feedback, Bias stabilization, Design of bias. Small Signals Modeling of BJT and their analysis: The r transistor model, Hybrid model, Graphical determination of h-parameters, Low frequency small signal analysis of CE, CC and CB configurations without feedback. DC Biasing of FETs: Fixed bias, Self bias and Voltage divider bias Configuration, Design of bias. Small Signal Modeling and Analysis of FETs: Small Signal Model, Analysis of JFET C-S and CD configuration.
