Features: 1. Support HDMI1.4b version. 2. Support ARC function. 3. Support 3D video format. 4. Support maximum resolution of up to 4096*2160/30Hz. 5. The TMDS clock is 320Mhz at the maximum rate of 3.2G. 6. Support 8/10/12 bit deep color. 7. When the resolution is 1080P or less, the standard AWG26 cable is supported. The input transmission distance is 15 meters, and the output transmission distance is 25 meters. 8. When the resolution is 4K, the standard AWG26 cable is supported. The input distance is 12 meters, and the output transmission distance is 15 meters. 9. It supports 3.5 mm stereo audio interface output and fiber output. 10. It supports switching or distributing 4 way HDMI input into 2 way HDMI output. 11. Support 5.1 channels. 12. Support 5V-12V wide voltage input. Specifications: HDMI version: HDMI 1.4b HDMI resolution: 4096*2160/30Hz Support video color format: 8/10/12 bit deep color Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Max bandwidth: 320MHz Maxbaud rate: 3.2Gbps Input cable distance: (resolution 1080p)?15m; (4K resolution)?12m; AWG26 HDMI standard cable Output cable distance: (resolution 1080p)?25m; (4K resolution)?15m; AWG26 HDMI standard cable HDMI input port: 4 HDMI output port: 2 Max working current: 1000mA Power adapter format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A Operating Temperature range: (-15 to +55
